Prefabricated Cold Storage Room
CSR（参考值）
Product gallery
Related cases
UAE Dubai Food Group Delegation Visits Henvic Shaoxing Facility
A 5-person delegation from a major Dubai-based food group visited Henvic's Shaoxing HQ and smart factory for a 2-day site visit. The delegation…
Regular After-Sales Service Visit to Zhejiang Frozen Food Enterprise
Henvic after-sales team completed a quarterly routine inspection of 3 sets of operating equipment for a major frozen food enterprise in Hangzhou…
Key facts
At a glance: Prefabricated Cold Storage Room (CSR（参考值）) — Capacity 10–500 m³（参考值）; Inlet temperature 环境温度; Outlet temperature 0~5℃ / -18℃ / -35℃ 多温区
- Capacity
- 10–500 m³（参考值）
- Inlet temperature
- 环境温度
- Outlet temperature
- 0~5℃ / -18℃ / -35℃ 多温区
The prefabricated cold storage room is built from modular PU sandwich panels on site, with four temperature zones (0~5℃, -5~0℃, ≤-18℃, -40~-35℃) using aluminum pipes and air coolers for raw-material holding, finished-product freezing and logistics.
Model range
| Model | Capacity | Dimensions | Freezing time |
|---|---|---|---|
| CSR-50 | 50 m³（参考值） | ||
| CSR-200 | 200 m³（参考值） | ||
| CSR-500 | 500 m³（参考值） |
Frequently asked questions
What is the freezing capacity of the Prefabricated Cold Storage Room?
The rated capacity is 10–500 m³（参考值）, depending on product shape, belt loading and inlet temperature.
What outlet temperature does the Prefabricated Cold Storage Room reach?
Product outlet temperature is 0~5℃ / -18℃ / -35℃ 多温区. This supports IQF freezing followed by cold storage at -18 °C or below.
Which food products is the Prefabricated Cold Storage Room suitable for?
Typical applications include 原料冷藏, 成品冷冻, 物流仓储.
How do I get a quotation for the Prefabricated Cold Storage Room?
Send the product type, required hourly capacity, inlet and outlet temperatures and site conditions through the contact form or WhatsApp. The engineering team replies with a technical proposal and price.
